90TAH10TDB Nachi Thrust Angular Contact Bearing 90x140x45 ABEC 7

90TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

• 90TAH10TDB Nachi Ball Bearing
• Nachi Angular Spindle Ball Bearing
• Cage: Phenolic resin
• Dimensions: 90mm x 140mm x 45mm/Metric
• ID (inner diameter)/Bore: 90mm
• OD (outer diameter): 140mm
• Width: 45mm
• Size: 90 x 140 x 45 mm
• Quantity: 1 Bearing
• Dynamic load rating Cr: 55,500 N
• Static load rating Cor: 135,000 N
• Limiting Speed:
  • Grease Lubrication: 6500 RPM
  • Oil Lubrication: 8200 RPM
• Made in Japan
