Nachi

5212ZZ Nachi Angular Contact Bearing - Double Row - 60x110x36.5 Bearing

5212ZZ Nachi Angular Contact Bearing - Double Row - 60x110x36.5 Bearing

$203.22 USD
$225.80 USD $203.22 USD
Sale Sold out
Shipping calculated at checkout.
5212ZZ Nachi Angular Ball Bearing
Double Shielded
60mm x 110mm x 36.5mm
Made in Japan

5212ZZ Nachi Double Row Angular Ball Bearing, Double Shielded, Made in Japan, diameter is 60mm, diameter is 110mm and width is 36.5mm.

  • 5212ZZ Nachi Ball Bearing
  • Nachi Double Row Angular Ball Bearing
  • Closures: Double Shielded
  • Dimensions: 60mm x 110mm x 36.5mm/Metric
  • ID (inner diameter)/Bore: 60mm
  • OD (outer diameter): 110mm
  • Width: 36.5mm
  • Size: 60 x 110 x 36.5 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 76,000 N
  • Static load rating Cor: 62,000 N
  • Limiting Speed:
    • Grease Lubrication: 4,300 RPM
  • Made in Japan

The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
