29318EX Nachi Spherical Roller Bearing
Steel Cage
90mm x 155mm x 39mm
Made in Japan

29318EX Nachi Spherical Roller Bearing, Steel Cage, Made in Japan, the 29318EX inner diameter is 90mm, the 29318EX outer diameter is 155mm and the 29318EX width is 39mm.

  • 29318EX Spherical Roller Bearing
  • Nachi Spherical Roller Bearing
  • Cage: Steel Cage
  • Dimensions: 90mm x 155mm x 39mm/Metric
  • ID (inner diameter)/Bore: 90mm
  • OD (outer diameter): 155mm
  • Width: 39mm
  • Size: 90 x 155 x 39 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 355,000 N
  • Static load rating Cor: 1,070,000 N
  • Limiting Speed:
    • Grease Lubrication: 1,600 RPM
    • Oil Lubrication: 2,700 RPM
  • Made in Japan

Nachi Spherical Roller Bearings are particularly suitable for applications where misalignment can arise from error in mounting or from shaft deflection. NACHI Spherical Roller Bearings are manufactured in a number of design and material configurations depending on the type of application and size of the bearing. Nachi Spherical Bearings have two designs, regular spherical roller bearings and spherical roller thrust bearings.
