100BAR10 Nachi Thrust Angular Contact Bearing 100x150x22.5 ABEC 7

100BAR10 Nachi Thrust Angular Contact Bearing 100x150x22.5 ABEC 7

$2,030.39 USD
$2,255.99 USD $2,030.39 USD
Promotion Épuisé
Frais d'expédition calculés à l'étape de paiement.
100BAR10 Nachi Thrust Load Angular Contact Ball Bearing
30 degrees Contact Angle
Abec-7
Made in Japan

100BAR10 Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

  • 100BAR10 Nachi Ball Bearing
  • Nachi Angular Spindle Ball Bearing
  • Cage: Phenolic resin
  • Dimensions: 100mm x 150mm x 22.5mm/Metric
  • ID (inner diameter)/Bore: 100mm
  • OD (outer diameter): 150mm
  • Width: 22.5mm
  • Size: 100 x 150 x 22.5 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 57,000 N
  • Static load rating Cor: 147,000 N
  • Limiting Speed:
    • Grease Lubrication: 6,000 RPM
    • Oil Lubrication: 7,600 RPM
  • Made in Japan
